Case 521G - Page 48

Engine-Engineandcrankcase
45.Removethetwobolts(1),thefourwashers(2),and
thetwonuts(3)toseparatetheclamps(4)and(6)
fromthebracket(8).
Removetheclamp(4)fromtheDEFbundle(5).Re-
movetheclamp(6)fromthehosecoolantassembly
(7).
LEIL15WHL0193BB42
46.Removethetwobolts(4),thewashers(5),thespacer
(10),andthenut(6)toseparatetheclamp(3)from
thebracket(11).Removetheclamp(3)fromthehose
coolantassembly(1).
47.Removethetwobolts(8),thewashers(9),andthe
nut(6)toseparatetheclamp(7)fromthebracket(11).
Removetheclamp(7)fromtheDEFbundle(2).
LEIL15WHL0261BB43
48082189_EN14/02/2017
10.1[10.001]/15
