Case 580SR - Machine Sides Orientation

INTRODUCTION, SAFETY, PLATES AND DECALS
1-5
MACHINE SIDES
The terms “right”, “left”, “front” and “rear”, when used
in this manual, indicate the sides of the machine as
seen from the operator’s seat.
Operator and seat in loader attachment position:
1. Front side
2. Back side
3. Right side
4. Left side
Operator and seat in backhoe attachment posi-
tion:
1. Front side
2. Back side
3. Right side
4. Left side
4
5
