2000-19
STEP 8
BD03A108
Loosen the upper radiator hose clamps, remove the
hose.
STEP 9
BD06F129
Loose and remove the lower radiator hose from the
radiator.
STEP 10
BD03A113
Disconnect overflow hose from radiator. Disconnect
connector from coolant level sender.
STEP 11
BD03A106
Remove screws and install lifting eyes (1). Attach
suitable lifting equipment to lifting eyes. Remove four
mounting bolts (2), remove radiator from machine.
