Engine-Engineandcrankcase
19.Putthetimeddisconnectswitch(1)inOFFposition.
Removethebatterycoveranddisconnectgroundlead
fromthebatteries(2).
RAPH12WEL0608AA19
20.Haveanotherpersontobalancethehoodandremove
thehoodhingemountingbolts(seethearrowsing-
ure)fromthecoolerframe.
LEIL13WHL0142AB20
21.Carefullyraiseandremovetheenginehoodfromthe
machine.Lowertheenginehoodontoasuitableplat-
formanddisconnectliftingequipmentfromtheex-
hauststack(1).
NOTE:radiatoroverowhosemayinterferewithleft-hand
hoodhingemovementandhoodremoval.
LEIL13WHL0552AB21
22.Taganddisconnecttheenginewiringharnesscon-
nectorfromtheairlterrestrictionswitch.
LEIL16WHL0573AB22
51428216_EN14/12/2017
10.1[10.001]/12
