Engine-Engineandcrankcase
16.Taganddisconnecttheenginehoodwiringharness
connector(1)fromtherearchassiswiringharness
connector.
Removetheenginehoodwireharnessclamp(2)from
thefanguard.
LEIL13WHL0150AB16
17.Haveanotherpersontobalancethehoodand
LOOSENthehoodhingemountingbolts(seethe
arrowsingure)fromthecoolerframe.
NOTE:donotremovetheenginehoodhingemounting
boltsatthistime.
LEIL13WHL0142AB17
18.Disconnectthewiringharness(5).
PutthetimeddisconnectswitchintheONposition.
Retracttheliftingmotorcylinder(1)andremovethe
clevispin(3)andthecotterpin(4)fromthebottomof
theliftingmotorcylinder(1).Separatetheliftingmotor
cylinder(1)fromthehoodsupportstrut(2).
LEIL16WHL1837BB18
51428216_EN14/12/2017
10.1[10.001]/11
