12.Placeasolidsteelbarorpipethroughthestraploop
insidetheenginehoodandattachthestraptoasuit-
ableliftingdevice.
Raisetheenginehoodwiththestraptoreleaseten-
sionontheliftingmotor.
RAPH12WEL0600AA12
13.Ifmachineisequippedwitharearviewcamera,tag
anddisconnecttheconnector(1)oftherearviewcam-
erawireharness(3).Cutthewireties(2)thatholdthe
rearviewcamerawireharness(3)tothereargrill.
LEIL16WHL0849AB13
14.Cutthewiretiesandremovetherearviewcamerawire
harnessfromtheenginehood.Placetherearview
camerawireharnessofftothesideinasafelocation.
LEIL13WHL0140AB14
15.Removetheenginehoodwireharnessclamp(1)from
thecoolerhousing.
Tagandremovetheenginehoodgroundwire(2)from
coolerhousing.
LEIL13WHL0149AB15
