Engine-Engineandcrankcase
8.Placeasuitablecontainerbelowtheradiatordrainplug,
removetheradiatorcapandtheradiatordrainplug(see
thearrowingure)todraintheenginecoolant.Then
reinstalltheradiatordrainplugandtheradiatorcap
aftercoolanthasdrained.
NOTE:seemachinespecicationsforcoolingsystemvol-
ume.
LEIL16WHL0198AA8
9.Placeasuitablecontainerbelowtheengineoildrain
plug(seethearrowingure).Removetheengineoil
drainpluganddrainoilintocontainer.Thenreinstall
theengineoildrainplug.
NOTE:seemachinespecicationsforengineoilsumpvol-
ume.
LEIL16WHL0198AA9
10.Removethedrainhose(1)fromtheframebracket(2).
LEIL16WHL1250AB10
11.Doubleupanylonliftingstrapandslidethroughthe
exhauststack(1)ontheenginehood.
LEIL13WHL0552AB11
