Engine-Engineandcrankcase
47.Loosentheclamp(1)ontheintakemanifoldforthe
outputhoseoftheaftercooler.
Loosentheclamp(2)fromthebodyofthe
DEF/ADBLUE®tankventlter.
LEIL13WHL0613AA47
48.Loosentheclampontheaftercooler,andremovethe
outputhoseoftheaftercoolerfromthemachine.
LEIL13WHL0162AB48
49.Taganddisconnectthefuellterheaterwire(1)and
thewatersensor(2).Thendrainfuellteranddiscon-
necttheinlet(3)andoutlet(4)fuellinesfromthefuel
lterhead.Plugthelinesandcapthettings.
Removethegroundwireandtheattachmentbolt(5)
ofthefuellterhead.
LEIL13WHL0163AB49
50.Tagandremovethegridheatercable(1).
NOTE:holdtherearnutwithasecondwrenchtoprevent
gridheaterdamage.
LEIL13WHL0164AB50
