Engine-Engineandcrankcase
51.Removewireharnesssupportclamp.
LEIL16WHL0490AB51
52.RemovetheP-clampandcutthecabletiesbythesup-
plymodule.Disconnecttheendofthejumperharness
(nearthesupplymodule)fromtheDieselOxidation
Catalyst(DOC)support.
LEIL15WHL0034AB52
53.Loosentheclamp(1)ontheDieselOxidationCatalyst
(DOC).
LEIL13WHL0166AB53
54.Taganddisconnecttheconnector(1).
LEIL13WHL0167AB54
51428216_EN14/12/2017
10.1[10.001]/20
