Case 860 - Perspective View

2000-6
PERSPECTIVE VIEW
CI98G505
Cre 7-21290GB Issued 10-99
9 7
6
28
8
2
1
4
17
16
17
16
19
21
18
12
15
2
25
26
3
22
27
23
13
11
10
14
15
5
25
16
24
26
22
21
20
1. Hose
15.
Washer
2. Collar
16.
Nut
3. Hose
17.
Bracket
4. Collar
18.
Bracket
5. Seal
19.
Collar
6. Shroud
20.
Nut
7. Radiator
21.
Hose
8. Cap, filler
22.
Clamp
9. Cooler, oil
23.
Tank, expansion
10. Bracket
24.
Bracket
11. Nut
25.
Screw
12. Screw
26.
Washer
13. Washer
27.
Plug
14. Stanchion
28.
Grommet
