Case Slot - Page 4

Supplied components
C - Grub Screw
A - Wall boss
B - Pin
D - Washer
E - Upright foot
I - Shelf
J - Upright
H - Allan Key
F - Screw
G - Wall Plug
I - Shelf
Required Tools
Pencil
Rule
Screw
Driver
Drill
Spirit
Level
Line up
here
1
600 width
Upright
900 width
Upright
Mark here for
600 width unit
2 i.
Mark here for
900 width unit
2 ii.
First
Upright
1
Slot into
Upright
Mark
here
2
K - Small
Slot template
L - Long
Slot template
Spirit
Level
Hammer
3
