Case SV300 - Engine Removal Procedure

Engine-Engineandcrankcase
Engine-Remove
SR270TIER4B(FINAL)[NFM481941-]
NA
SV300
TR340TIER4B(FINAL)[NFM482972-]
NA
TV380
WARNING
Avoidinjury!Alwaysdothefollowingbeforelubricating,maintaining,orservicingthemachine.
1.Disengagealldrives.
2.Engageparkingbrake.
3.Lowerallattachmentstotheground,orraiseandengageallsafetylocks.
4.Shutoffengine.
5.Removekeyfromkeyswitch.
6.Switchoffbatterykey,ifinstalled.
7.Waitforallmachinemovementtostop.
Failuretocomplycouldresultindeathorseriousinjury.
W0047A
WARNING
Firehazard!
Whenhandlingdieselfuel,observethefollowingprecautions:
1.Donotsmoke.
2.Neverllthetankwhentheengineisrunning.
3.Wipeupspilledfuelimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0099A
WARNING
Escapinguid!
Hydraulicuidordieselfuelleakingunderpressurecanpenetratetheskinandcauseinfectionor
otherinjury.Topreventpersonalinjury:Relieveallpressurebeforedisconnectinguidlinesorper-
formingworkonthehydraulicsystem.Beforeapplyingpressure,makesureallconnectionsaretight
andallcomponentsareingoodcondition.Neveruseyourhandtocheckforsuspectedleaksunder
pressure.Useapieceofcardboardorwoodforthispurpose.Ifinjuredbyleakinguid,seeyour
doctorimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0178A
WARNING
Heavyobjects!
Liftandhandleallheavycomponentsusingliftingequipmentwithadequatecapacity.Alwayssupport
unitsorpartswithsuitableslingsorhooks.Makesuretheworkareaisclearofallbystanders.
Failuretocomplycouldresultindeathorseriousinjury.
W0398A
Prioroperation:
TilttheROPS.
Prioroperation:
Disconnectthebattery.
Prioroperation:
Drainthecoolant.
Prioroperation:
Draintheengineoil.
Prioroperation:
EvacuatetheA/Csystem(ifequipped).
