Engine-Engineandcrankcase
15.Engagethehydrostaticdriveassembly(2)totheen-
ginebellhousing(1).
9310019367
16.ApplyLOCTITE®243™tothethreadsofthemounting
bolts(1)forthehydrostaticdriveassembly.
17.Installthemountingbolts(1).T orquethemounting
bolts(1)forthehydrostaticdriveassemblyto87-
117N·m(64-86lbft).
9310019288
18.Ifyourmachinehasacabheater,connecttheheater
hose(1)totheengine.
19.ConnectthePclamp(2)forthehydrauliclinetothe
bellhousing.
RAPH12SSL0058AA9
20.Connectthelines(1)fortheremote,engineoillterto
theengine.
93100192310
