COMPANY POLICY
Company policy, which is one of continuous improvement, reserves the right to make changes in design and
specification, without notice and without obligation to modify units previously built.
All data given in this book is subject to production variations. Dimensions and weights are approximate only and
the illustrations do not necessarily show machines in standard condition. For exact information about any
particular machine please consult your dealer.
PARTS AND ACCESSORIES
Genuine parts and accessories have been specifically designed for these machines.
We would like to point out that “non--genuine” parts and accessories have not been examined and released by
Builder. The installation or use of such products could have negative effects upon the design characteristics of
your machine, and thereby affect its safety. The Builder is not liable for any damage caused by the use of
“non--genuine” parts and accessories.
MODEL CODES
The complete range of telescopic handlers (Telehandler) described in this manual is identified in the text by
reference to the maximum extension of the telescopic arm.
The vehicles listed below may not be available in all countries or markets, therefore for the latest information
consult your authorised dealer.
Model LM1340 LM1343 LM1345 LM1443 LM1445 LM1745
Stabilisers no small large small large large
Engine 82 kW (110 CV -- 118 HP) Turbo Aftercooler
Max. lifting
height (m)
12.300 12.450 12.450 13.550 13.550 16.600
Max. capacity (kg)
at 500 mm from
fork stop
4000 4300 4500 4300 4500 4500
Capacity at max.
height (kg)
2600 3600 4000 3000 3600 2500
Extension at max.
height (m)
1.200 0.500 0.000 0.500 0.300 1.000
Max. longitudinal
extension (m)
8.650 9.330 12.540
Capacity at max.
extension (kg)
700 1700 1800 1400 1500 450
Weight (kg) 10480 10780 11760
Length (m) 5.850 6.070 6.135
