˚C
mb
hPa
A
B
D
C
• For details on viewing the temperature in the Altimeter Mode, see
“Understanding the altimeter display”.
Calibrating the temperature measurement
The temperature sensor of this watch is calibrated at the factory before
shipment and further adjustment is normally not required. If noticeable error is
found in the temperature readings produced by the watch, you can adjust it to
correct the error.
Important!
Incorrectly calibrating the temperature measurement of this watch can result in
incorrect readings. Carefully read the following before doing anything.
• Compare the readings produced by the watch with those of another reliable,
accurate thermometer.
• If adjustment is required, remove the watch from your wrist and wait for 20
or 30 minutes to give the temperature of the watch time to stabilize.
To calibrate the temperature
1. In the Timekeeping Mode, use D to
display the barometric pressure and
temperature.
2. Hold down A until the display clears.
OFF
or the temperature value should be flashing
on the display.
• The
OFF indicator appears when the factory
setting is being used for the calibration.
3. Each press of D increases the displayed temperature by 0.1°C while
pressing B decreases it. Holding down either button changes the value at
high speed.
• If you have selected Fahrenheit as your unit of measurement, the above
operations change the reading by 0.2°F.
• Pressing B and D at the same time returns to the
OFF display.
4. After calibrating the temperature, press A to return to the Barometric
Pressure/Temperature screen.
• If you do not operate any button for a few minutes while the temperature
digits are flashing, the flashing stops and the watch goes back to the
Barometric Pressure/Temperature screen.
km
STEP
A
B
D
C
TREKKING COUNTER FUNCTIONS
The trekking counter uses a vibration sensor to
count how many steps you take. It also records
the amount of time you spend walking. After
you input the length of your stride, it also
automatically calculates and displays the
distance you have covered.
Important!
• The watch must be hanging free in order for
the vibration sensor to work, so the trekking
counter cannot count the number of steps
you take if the watch is on your wrist. Be
sure to wear the watch on your waist.
• Note that the accuracy of data measured by the trekking counter can be
affected when you are walking on sand or other soft ground, on a steep
upgrade, on a steep downgrade, or on stairs.
• Be sure to take care not to drop the watch while walking.
• To improve the accuracy of measured data, be sure to turn off the trekking
counter whenever you are taking a break or stop walking for any other
reason.
• Be sure to select a unit of measurement before using the trekking counter.
Metric Units: stride length = centimeters, distance = kilometers
Inch/Mile Units: stride length = inches, distance = miles
Graphic area
Mode indicator
Distance
Elapsed time (hours,
minutes, seconds)
Steps
cm
A
B
D
C
Changing the trekking counter measurement units
1. Use C to enter the Trekking Counter
Mode.
2. Hold down A until the stride length value
flashes on the display. The stride length
value flashes because it is
selected
.
3. Press C to change the selection in the
following sequence.
Measurement unitStride
• When the measurement unit is selected, the currently set measurement unit
symbols (km/cm or mi/in) also flashes on the display.
4. Press B or D to toggle the measurement unit between metric units (km/
cm) and inch/mile units (mi/in).
5. After you are finished making the setting you want, press A to return to
the Trekking Counter Mode.
• If you do not operate any button for a few minutes while a selection is
flashing, the flashing stops and the watch goes back to the Trekking
Counter Mode automatically.
• Note that changing the units automatically clears the stride length setting.
This means that if you want to the trekking counter to calculate and display
the distance you cover, you must re-input your stride length whenever you
change the units.
Setting your stride length
1. In the Trekking Counter Mode, hold down
A until the stride length value flashes on
the display.
2. Each press of D increases the value by 1,
while B decreases it. Holding down either
button changes the value at high speed.
• You can set a stride length in the range of 20
to 200 cm or 10 to 80 inches.
3. After you finish making the setting, press
A to return to the Trekking Counter Mode.
Using the trekking counter
1. Attach the watch correctly to your belt.
• See “BAND CLIP” for details. The procedure you should use depends on
the type of band (cloth, leather, metal) that comes with your watch.
2. Press D while in the Trekking Counter Mode to start the trekking counter
operation.
• Elapsed time, number of steps, and distance covered are all shown on the
display while the trekking counter is operating.
3. Press D to temporarily stop trekking counter operation.
• You can use D to stop and re-start trekking counter operation as many
times as you like. Each time you press D to re-start, the elapsed time,
number of steps and distance covered values start from point they were at
when you press D to stop trekking counter operation.
• The trekking counter operation continues internally even if you change to
another mode.
• If you change the stride length setting while a trekking counter operation is
in progress causes the trekking counter operation to pause. Pressing D
resumes the operation.
4. After you are finished using the trekking counter, press D to stop
operation and then press B to clear all of the values to zero.
• The trekking counter is not intended for use as an all-day pedometer.
Trekking counter operation requires considerable battery power, so be sure
to press D to stop its operation after you are through using it. Next, hold
down C for about two seconds to return to the Timekeeping Mode.
• To protect against prematurely running down the battery, trekking counter
operation turns off automatically and the watch emits a 2-second beep to
alert you if the trekking counter is left on for more than 24 hours. Note that
measured values up to the point that the trekking counter turns off are
retained, so you can start the next operation from the displayed values.
• While the trekking counter is operating, the graphic area of the display
indicates the number of steps you have taken. The first block flashes during
steps 0 through 999. At step 1,000, the first block stays on and the second
block flashes from steps 1,000 to 1,999. This continues block-by-block until
step 9,999. At step 10,000, the first block flashes and the process starts
again. The display below that the number of steps is in the range of 4,000 to
4,999 (or 14,000 to 14,999, 24,000 to 24,999, etc.).
