Casio 5141 User Manual

Operation Guide 5141 (OC)
E-15
Signal reception may be diffi cult or even impossible under the conditions described below. x
Inside or among
buildings
Inside a vehicle Near household
appliances,
offi ce
equipment, or a
mobile phone
Near a
construction
site, airport, or
other sources of
electrical noise
Near high-
tension power
lines
Among
or behind
mountains
What you should do next depends on whether you are using Auto Receive or Manual Receive.3.
Auto Receive: Leave the watch over night in the location you selected in step 2. See “Auto Receive” x
on page E-15 for details.
Manual Receive: Perform the operation under “To perform manual receive” on page E-16. x
Auto Receive
With Auto Receive, the watch performs the receive operation each day automatically up to six times (up
x
to fi ve times for the Chinese calibration signal) between the hours of midnight and 5 a.m. (according
to the Timekeeping Mode time). When any receive operation is successful, none of the other receive
operations for that day are performed.
When a calibration time is reached, the watch will perform the receive operation only if it is in the
x
Timekeeping Mode. The receive operation is not performed if a calibration time is reached while you
are confi guring settings.
E-14
To get ready for a receive operation
Confi rm that the watch is in the Timekeeping Mode. If it isn’t, push in and hold the crown for at least two 1.
seconds to enter the Timekeeping Mode.
Place the watch in a location where signal reception is good.2.
12 o’clock
or
Position the watch as shown in the nearby illustration, x
with 12 o’clock pointed towards a window. Make sure
there are no metal objects nearby.
Signal reception normally is better at night.
x
The receive operation takes from two to seven minutes, x
but in some cases it can take as long as 14 minutes.
Take care that you do not perform any button operation
or move the watch during this time.
E-13
Even when the watch is within range of a transmitter, signal reception may be impossible due to the x
effects of geographic contours, structures, weather, the time of year, the time of day, radio interference,
etc. The signal becomes weaker at distances of approximately 500 kilometers, which means that the
infl uence of the conditions listed above becomes even greater.
Signal reception may not be possible at the distances noted below during certain times of the year or
x
day. Radio interference may also cause problems with reception.
Mainfl ingen (Germany) or Anthorn (England) transmitters: 500 kilometers (310 miles)
−
Fort Collins (United States) transmitter: 600 miles (1,000 kilometers) −
Fukushima or Fukuoka/Saga (Japan) transmitters: 500 kilometers (310 miles) −
Shangqiu (China) transmitter: 500 kilometers (310 miles) −
As of June 2010, China does not use Daylight Saving Time (DST). If China does go to the Daylight x
Saving Time system in the future, some functions of this watch may no longer operate correctly.
Using this watch in a country covered by a time calibration signal that is different from the countries it x
supports may result in incorrect time indication due to local application of summer time, etc.
E-12
Approximate Reception Ranges
Japanese Signals Chinese Signal
Fukushima
500 kilometers
1,000 kilometers
Fukuoka/Saga
1,500 kilometers
Changchun500 kilometers
Beijing
Shangqiu
Shanghai
Chengdu
Hong Kong
UK and German Signals North American Signal
Anthorn
500 kilometers
1,500 kilometers
Mainfl ingen
The Anthorn signal is receivable
within this area.
2,000 miles
(3,000 kilometers)
600 miles
(1,000 kilometers)
Fort Collins
E-11
Radio Controlled Atomic Timekeeping
This watch receives a time calibration signal and updates its time setting accordingly. However, when
using the watch outside of areas covered by time calibration signals, you will have to adjust the settings
manually as required. See “Confi guring Current Time and Date Settings Manually” (page E-31) for more
information.
This section explains how the watch updates its time settings when the city code selected as the Home
City is in Japan, North America, Europe, or China, and is one that supports time calibration signal
reception.
If your Home City Code setting is this:
The watch can receive the signal from the transmitter
located here:
LONDON (LON), PARIS (PAR), ATHENS (ATH) Anthorn (England), Mainfl ingen (Germany)
HONG KONG (HKG) Shangqiu City (China)
TOKYO (TYO) Fukushima (Japan), Fukuoka/Saga (Japan)
HONOLULU (HNL), ANCHORAGE (ANC),
LOS ANGELES (LAX), DENVER (DEN),
CHICAGO (CHI), NEW YORK (NYC)
Fort Collins, Colorado (United States)
Important!
The areas covered by
x HONOLULU (HNL) and ANCHORAGE (ANC) are quite far from the calibration
signal transmitters, so certain conditions may cause reception problems.
When
x HONOLULU (HNL) or HONG KONG (HKG) is selected as the Home City, only the time and date
are adjusted according to the time calibration signal. You need to switch manually between standard
time and daylight saving time (DST) if required. See “To toggle the Home City time between standard
time and daylight saving time” (page E-29) for information about how to do this.
E-10
The above times are for reference only. Actual times depend on lighting conditions. x
For details about the operating time and daily operating conditions, see the “Power Supply” section of x
the Specifi cations (page E-53).
Power Saving
Power Saving enters a sleep state automatically whenever the watch is left for a certain period in an area
where it is dark. The table below shows how watch functions are affected by Power Saving.
There actually are two sleep state levels: “second hand sleep” and “function sleep”.
x
Elapsed Time in Dark Operation
60 to 70 minutes (second hand sleep)
x
x
Second Hand only stopped at 12 o’clock, all other functions enabled
6 or 7 days (function sleep)
All functions, including analog timekeeping, disabled
x
Internal timekeeping maintained x
The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is already in a sleep x
state when 6:00 AM arrives, however, it will remain in the sleep state.
The watch will not enter a sleep state while it is in the Stopwatch Mode x or Countdown Timer Mode.
To recover from the sleep state
Move the watch to a well-lit area or press any button.
E-9
When power drops to Level 3, all functions will be disabled but the watch will continue to keep time x
internally for about one week. If you recharge the battery suffi ciently during this period, the analog
hands will move automatically to the correct setting and regular timekeeping will resume. After one
week, all settings (including timekeeping) will be cleared. Recharging the battery will reset all settings
to their initial factory defaults.
Power Recovery Mode
The watch is designed to go into a power recovery mode that stops hand operation temporarily whenever
power suddenly drops below a certain level due to overuse of the alarm tone over a short period. Note
that all operations are disabled while the watch is in the power recovery mode.
The hands will move to the correct positions and the watch will resume normal operation after power
recovers (in about 15 minutes). Putting the watch in a location where it is exposed to light will help power
to recover sooner.
Charging Times
Exposure Level (Brightness)
Daily
Operation *1
Level Change *2
Level 3 Level 2 Level 1
Outdoor sunlight (50,000 lux) 8 minutes 2 hours 21 hours
Window sunlight (10,000 lux) 30 minutes 5 hours 77 hours
Window sunlight on cloudy day (5,000 lux) 48 minutes 8 hours 124 hours
Indoor fl uorescent lighting (500 lux) 8 hours 84 hours – – –
1 Approximate exposure each day to generate power for normal daily operation. *
2 Approximate exposure to take power up one level. *
E-8
Important!
Keep the watch in an area normally exposed to bright light when storing it for long periods. This helps
x
to ensure that power does not run down.
Storing the watch for long periods in an area where there is no light or wearing it in such a way that it is
x
blocked from exposure to light can cause power to run down. Make sure that the watch is exposed to
bright light whenever possible.
Power Levels
You can get an idea of the watch’s power level by observing the movement of
the
x
Second Hand in the Timekeeping Mode.
If the
x
x
Second Hand is moving normally at one-second intervals, power is
at Level 1.
If the
x
x
Second Hand is moving at two-second intervals, power is at Level
2, which is quite low. Expose the watch to light as soon as possible so it
can charge.
Level Hand Movement Function Status
1 Normal. All functions enabled
2
x
x
Second Hand moves at two-second
intervals.
n
n
Day changes to 1 (home position).
Beeper, time calibration signal
reception, and countdown timer
operation disabled
3
x
x
Second Hand stopped.
z
z Hour Hand and c
c
Minute Hand
stopped at 12 o’clock.
All functions disabled

+
6
@
B
Moves at two-second
intervals.
