Casio AP-20 Service Manual

FOB Japan
N Item Code No. Parts Name Specification Q N.R.Yen R
Unit Price
Other electrical parts
6
3012 0567 Transformer TE-351-1M1
1 2,040 B
7
3613 0217 Receptacle NC-174-10-C
1 110 B
N
8
3412 1827 Power switch SDDLD1-A2-D
1 130 A
Keyboard unit
N 9 6924 1820 Keyboard unit 88TP/10CASIO
1 13,340 B
N 10 - 16 6924 9150
White key set, 1-octave
88TP10(42120120)
7 540 A
N 19 6924 9150
Black key, 1-octave
88TP10(42120030)
7 540 A
N 20 6924 9160
Spring, for white key
88TP10(23100820)
52 15 B
N 21 6924 9170
Spring, for black key
88TP10(23100810)
36 15 B
N 22 6924 9190
Contact, rubber, for key, 12
88TP10/8(2564230)
6 150 A
N 23 6924 9200
Contact, rubber, for key, 13
88TP10/8(2564240)
1 160 A
N 24 6924 9060
Keyboard PCB (DX)
88TP10/8(42912070)
1 2,800 C
N 25 6924 9070
Keyboard PCB (SX)
88TP10/8(42912080)
1 3,500 C
Mechnical parts
26 3831 0546 Speaker EAS-16PL465A
2 1,250 B
27 6906 6141
Felt for keyboard
M410324A-4
1 140 B
6919 7410 Sponge for felt M411750-1
819B
28 6924 5390
Rack L
1037153000
1 170 B
29 6924 5410 Rack R 1037154009
1 170 B
30 6919 3241 Slide knob A 353 M311405A-1
217B
31 6924 5260 Button, power switch M340318-1 1 13 B
N 32 6924 5600 Button set 433 M240304*1
1 170 B
Stand
33
6924 7050 Pedal box ass'y A190007400
1 5,120 B
N34
6924 7060 Screw set for AP-20's stand A190007500
1 600 B
AC cord
3701 0196 AC cord (120V, USA) UC-964-J01
1 650 B
3701 0595 AC cord (230V, Europe) EC-654-E06
1 720 B
3701 0588 AC cord (230V, UK) BC-323-J01
1 860 B
N
3701 0553 AC cord (240V, Australia) SC-101-J02
1 660 B
Notes: N – New parts
R – Rank
— 22 —
