42
Part VII
Setting Values and Send/
Receive Values
26 Setting Value Tables
26.1 Off/On Setting Value Table
26.2 –64 - 0 - +63 Setting Value Table
26.3 Pan Setting Value Table
26.4 –100 - 0 - +99 Setting Value Table
26.5 Reverb Type Setting Value Table
26.6 Chorus Type Setting Value Table
Transmit Value Receive Value Parameter
00H 00H - 3FH Off
7FH 40H - 7FH On
Transmit/Receive Value Parameter
00H –64
01H –63
::
40H 0
::
7EH +62
7FH +63
Transmit/Receive Value Parameter
00H Left
::
40H Center
::
7FH Righet
Transmit/Receive Value Parameter
(MSB-LSB)
00H - 00H –100
::
40H - 00H 0
::
7FH - 7FH +99
Transmit /
Receive Value
Parameter
Panel
Number
00H Room1 -
01H Room2 1
02H Room3 -
03H Hall1 3
04H Hall2
2(default)
05H Plate1 -
06H Delay -
07H Panning Delay -
08H Plate2 -
09H Plate3 -
0AH Large Room1 -
0BH Large Room2 -
0CH Stadium1 4
0DH Stadium2 -
0EH Long Delay -
0FH
Long Panning Delay -
Transmit /
Receive Value
Parameter
Panel
Number
00H Chorus1
1
01H Chorus2 -
02H Chorus3
2(default)
03H Chorus4 -
04H Feedback Chorus -
05H Flanger1 -
06H Short Delay -
07H Short Delay FB -
08H Soft Chorus -
09H Bright Chorus -
0AH Deep Chorus 3
0BH Flanger2 4
0CH Flanger3 -
0DH Flanger4 -
0EH
Short Delay
Modulation
-
0FH
Short Delay
Modulation FB
-
