Casio AP-22S User Manual

Item Code No. Parts Name Specification Q R
Main PCB
BT1 3815 0794 BATTERY/LITHIUM CR2032/1VC1 1 B
D1 - D5 2390 2555 DIODE/SHOTTKY RB500V-40TE-17 5 B
D6 2360 3057 DIODE/ZENER UDZTE-173.3B 1 A
IC1 2105 1120 IC/MOS TC7S08F-TE85R 1 B
IC2 2105 6354 IC/MOS TC74HC27AF(TP1) 1 B
IC3 2105 6353 IC/MOS TC74HC11AF(TP1) 1 B
IC4 2105 6355 IC/MOS TC7S00F(TE85R) 1 B
IC5 2114 4060 IC MB3771PF-EF 1 B
LSI1 2012 5844 LSI HD6435328RF35F 1 A
LSI10 2011 5194 LSI/KEY CONTROLLER HG52E35P 1 A
LSI2 2012 5843 LSI MX23C8000MC-12CA73 1 A
LSI3/8/9 2012 5572 LSI/RAM TC55257DFL-70L(EL) 3 A
LSI4/5 2114 4221 LSI/DAC UPD6376GS-E1 2 A
LSI6 2012 5707 LSI MX23C2410MC-12CA58 1 A
LSI7 2012 1316 LSI/DSP HG51B155FD-1 1 A
Q1 - Q3 2250 1162 TRANSISTOR 2SA1576AT106R 3 A
Q4 2252 0637 TRANSISTOR 2SC4081T106R 1 A
SNF1 3025 1505 CHIP EMI FILTER NFM51R00P106 1 B
X1 2590 2100 OSCILLATOR/CERAMIC CSACS20.00MX040-TC 1 B
X2 2590 2709 OSCILLATOR/CERAMIC HC-49US16384 1 B
1 6926 1980 M434-MA1M PCB ASSY M140657*1 1 A
Console PCBs
LED306 - LED332 2370 0630 LED LN282RPX-(TX3) 27 B
LED302 2370 1386 LED LN282RPX(V)-(TX2) 1 B
LED303 - LED305 2370 0679 LED LN382GPX-(TX2) 3 B
LED301 2370 0497 LED LB-603VP 1 B
IC301 2114 3318 IC BA612 1 B
LSI301 2011 0812 LSI UPD65005GF-419 1 A
Q309 - Q312 2220 1409 TRANSISTOR 2SC1740SR-TP-T 4 A
Q301 - Q308 2259 1883 TRANSISTOR DTA114TS-TP-T 8 A
SW301 - SW329 3412 0903 SWITCH/TACT EVQ-21405R 29 A
VR301 2765 0280 POTENTIOMETER EWA-NAXCH1B14 1 A
VR302 2765 2187 POTENTIOMETER EWA-NFECH1B54 1 A
2 6926 2060 M434-CN1M PCB ASSY M140658*1 1 A
2 6926 2070 M434-CN2M PCB ASSY M140659*1 1 A
Power supply PCBs
D405 - D408 2390 3022 DIODE 3BZ41(LC6-15) 4 B
D416 2390 1323 DIODE RB100A-T32-T 1 B
D422/423 2360 1729 DIODE MTZJ5.1AT-77-T 2 B
F402 3632 0273
FUSE/TIME-LAG (US,CANADA)
UL-TSC-1.6A-N1 1 A
F402
3631 1045
FUSE/TIME-LAG (OTHERS)
(S)T-1.6A 1 A
F403/406
3632 0420
FUSE/TIME-LAG (US,CANADA)
UL-TSC-6.3A-N1 2 A
F403/406
3632 0427
FUSE/TIME-LAG (OTHERS)
(S)T-6.3A 2 A
IC401 2114 5794 IC NJM78M15FA 1 B
IC402 2114 5795 IC NJM79M15FA 1 B
IC403 2114 5797 IC NJM78L05A(T3) 1 B
IC404 2114 3444 IC NJM7805FA 1 B
IC405 2114 2149 IC STK4152MK2 1 B
IC406/408/410/411 2114 1799 IC M5218APR 4 B
IC409 2252 1248 IC/PHOTO COUPLER HCPL-261A 1 B
J401/402 3612 0584 JACK YKB21-5012 2 A
J403/404 3612 0789 JACK YKB21-5010 2 A
J405 3501 4816 JACK/DIN YKF51-5051 1 B
Q401 - Q404 2254 0551 FET 2SK365-BL(TPE4) 4 A
Notes: Q – Quantity per unit
R – Rank
— 23 —

Casio AP-22S Specifications

General

Brand	Casio
Model	AP-22S
Category	Electronic Keyboard
Language	English
