Item Code No. Part Name Specification Q R
4 6926 5800 M434-PS2M PCB ASSY
(US,CANADA,DIRECT 110 - 127V AREA)
4
M434-PS2M PCB ASSY
(EU,DIRECT 220 - 240V AREA)
PS11, PS3, PS4 PCBs
J406 3613 1533 JACK HLJ4336-01-3040 1 A
F401 3632 0720
FUSE/TIME-LAG (US,CANADA)
MT4-3.15A-N1 1 A
F401 3631 1045
FUSE/TIME-LAG (OTHERS)
(S)T-1.6A 1 A
L401 3013 2577 COIL/CHOKE PLAC1522R0R01B1 1 B
LED401 2320 9748 LED LN28RPH 1 B
SW402 3613 1740 VOLTAGE SELECTOR HXW1219-01-110 1 B
5 6926 2160
M434-PS11 PCB ASSY
(US,CANADA,DIRECT 110 - 127V AREA)
5
M434-PS11 PCB ASSY
(EU,DIRECT 220 - 240V AREA)
6 6926 2030 M434-PS3M PCB ASSY M340697*1 1 A
7 6926 2290 M434-PS4M PCB ASSY M340698*1 1 A
Other electrical parts
8 3831 1077 SPEAKER SG16G51BFA 2 B
9 3831 1075 SPEAKER/TWEETER S05JH37A 2 B
10
3613 0217 RECEPTACLE NC-174-10-C
1B
11 3012 1593 TRANSFORMER TE-434-1M1 1 B
Keyboard unit
12 6926 0370 KEYBOARD UNIT 88TP/20CASIO 1 B
13 6926 4890 HAMMER/WHITE KEY 88TP/20(42366750) 52 B
14 6926 4900 HAMMER/BLACK KEY 88TP/20(42366790) 36 B
15 6926 4940 SPRING/FOR KEY 88TP/20(23002160) 88 B
16 6926 4950 WHITE KEY/ 1-OCTAVE 88TP/20(42123920) 7 A
17 6926 4960 BLACK KEY/1-OCTAVE 88TP/20(42123910) 7 A
18 6926 5280 INITIAL KEY/A0 88TP/20(42328510) 1 A
19 6926 5290 FINAL KEY/C0 88TP/20(42328500) 1 A
20 6924 9060 PCB/KEYBOARD (DX) 88TP/20(42912070) 1 C
21 6924 9070 PCB/KEYBOARD (SX) 88TP/20(42912080) 1 C
22 6924 9080 FLAT CABLE 88TP/20(42901000) 1 C
23 6924 9190 CONTACT/RUBBER 88TP/20(2564230) 1 B
24 6924 9200 CONTACT/RUBBER 88TP/20(2564240) 1 B
Mechnical parts
26 6926 1740 BUTTON SET 434 M240744*1 1 B
27 6924 5260 BUTTON/POWER M340318-1 1 B
28 6919 3240 KNOB/SLIDE M311405-1 2 A
29 6924 4710 SWITCH ASSY/POWER M340337*1 1 B
30 6926 2440 PANEL/DISPLAY M240668-1 1 C
31 6926 2450 PLATE/DISPLAY M340658-1 1 C
32 6924 5120 SHAFT M440300-1 1 C
33 6924 5140 GEAR 4247002100 2 C
Stand
34 6926 5960 PEDAL BOX CA025/030 1 B
35 6926 5410 SCREW SET CA025/020 1 B
AC cord
3701 0196 AC CORD (120V,USA) UC-964-J01 1 C
3701 0595 AC CORD (230V,Europe) EC-654-E06 1 C
3701 1008 AC CORD (230V,UK) SP22-17022A 1 C
3701 0553 AC CORD (240V,AUSTRALIA) SC-101-J02 1 C
Notes: Q – Quantity per unit
R – Rank
M340695*1 1 A
M140654*2
M140654*3
1
1
A
A
M340695*2 1 A
— 24 —
