Casio CDP-200R Service Manual & Parts List

– 2 –
SD Memory Cards
Supported SD Memory Cards
Functions
Inputs/Outputs
USB port
Sustain/Assignable jack
Phones/Output jack
Audio In jack
Mic In jack
Power Jack
Power Supply
AC Adaptor
Speakers
Output
Power Consumption
Dimensions
Weight
2GB or less
SMF playback, file storage, file recall, file delete, card format
TYPE B
Standard jack (sustain, sostenuto, soft, rhythm start/stop)
Stereo standard jack
Output Impedance: 20Ω, Output Voltage: 1.5V (RMS) MAX
Stereo mini jack
Input Impedance: 40kΩ, Input Sensitivity: 200mV
Standard jack
Input Impedance: 3kΩ, Input Sensitivity: 10mV
12V DC
AD-12
(12cm × 6cm oval) × 2
8W + 8W
12V 18W
133.3 × 27.8 × 13.3cm (52
1
/
2
× 10
15
/
16
× 5
1
/
4
inch)
Approximately 12.0kg (26.4 lbs)

Casio CDP-200R Specifications

General

MIDI-keyboard number of keys	88 keys
Product color	Black
Pitch bend wheel	Yes
Interface	USB
Dimensions (WxDxH)	1333 x 278 x 133 mm
Power consumption (typical)	18 W

Weight and Dimensions

Weight	12000 g
