10
Getting Started
REG2 X1
REG1 Z1
OFF X2/Z2
RF
PGM
Install receipt/journal paper.
Loading journal paper
The same type of paper (45 mm × 83 mm i.d.) is used for receipts and journal. Load the new paper before first
operating the cash register or when red paper appears from the printer.
11
11
1
Use a mode key to set the
mode switch to REG1
position.
22
22
2
Open the printer cover.
33
33
3
Cut off the leading end of
the paper so it is even.
44
44
4
Ensuring the paper is being
fed from the bottom of the
roll, lower the roll into the
space behind the printer.
55
55
5
Drop the paper roll gently
and insert paper to the
paper inlet.
66
66
6
Press the j key until
about 20 cm to 30 cm of
paper is fed from the
printer.
77
77
7
Slide the leading end of the
paper into the groove on
the spindle of the take-up
reel and wind it onto the
reel two or three turns.
8.
To Next Page
