E-30
Assembling the Stand
8.
Affix the adaptor cord clip
K
next to the
power terminal (DC12V).
• For information about securing the cord, see “Power
Outlet” on page E-4.
1.
Orienting the pedal plug as shown in the
illustration, plug it into the pedal connector on
the bottom of the piano.
• Secure the pedal cord with the clip
G
.
1.
Install the music stand by inserting its pegs
into the holes in the top of the piano.
To connect the pedal cord
K
DC 12V terminal
G
Pedal plug
To install the music stand
