Item Code No. Parts Name Specification Q R
Main PCB
1 6925 9150 PCB/ASSY (MA1M) M240661*1 1 A
LSI1 2012 4494 LSI,DSP HG51B277FB-1 1 A
LSI2 2012 1764 LSI/S-RAM LC3564SM-85-TRM 1 A
LSI3 2012 5669 LSI/MASK-ROM UPD23C16000WGX-C54 1 A
LSI4 2012 5005 LSI,CPU GT913F(T) 1 A
LSI5 2012 5572 LSI/S-RAM TC55257DFL-70L(EL) 1 A
LSI6 2105 4746 LSI/D/A CONVERTER UPD6379GR-E1 1 A
IC1 2105 6340 IC/MOS (RESET IC) RN5VD35AA-TR 1 B
Q1 2252 0637 TRANSISTOR 2SC4081-T106R 1 B
Q2 2250 1162 TRANSISTOR 2SA1576A-T106R 1 B
X1 2590 2387 OSCILLATOR/CRYSTAL HC-49/US24B 1 A
X2 2590 2079 OSCILLATOR/CERAMIC CSACS16.00MX040-TC 1 A
Sub PCB
2 6925 9180 PCB/ASSY (MA2,3,4M) M140596*1 1 B
IC101 2114 1883 IC/LINEAR LA4620 1 A
IC102 ~ 104 2114 1799 IC/LINEAR M5218APR 3 B
IC105 2252 1248 IC/PHOTO COUPLER HCPL-261A 1 B
Q101 2251 0672 TRANSISTOR 2SB1548-P.CS 1 A
Q102,Q104~106,
Q109~111
2220 1387 TRANSISTOR 2SC1740SQ-TP-T 7 A
Q103 2250 0168 TRANSISTOR 2SA854-SR-TP-T 1 A
Q107/108 2253 0420 TRANSISTOR 2SD1468SR.S-TP-T 2 A
D101/102 2390 1463 DIODE,SCHOTTKY SB20-03B 2 B
D102/103/107,
D109/113
2390 1344 DIODE 1SS133T-77-T 5 B
D104/105/D111 2360 1946 DIODE/ZENER MTZJ5.6CT-77-T 2 A
D108 2360 1085 DIODE/ZENER HZS6B1LTD-T 1 A
D110 2360 1939 DIODE/ZENER MTZJ5.1CT-77-T 1 A
J101 3501 5012 JACK/POWER HEC2305-01-920 1 A
J102/103, J106 3612 0789 JACK YKB21-5010 3 B
J104/105 3612 0584 JACK YKB21-5012 2 B
J107 3501 4816 JACK/DIN YKF51-5051 1 B
J108 3612 0665 JACK YKB21-5006 1 B
Console PCBs
3 6925 9190 PCB/ASSY (CN1,3M) M240662*1 1 B
D201 ~ 215 2390 1344 DIODE 1SS133T-77-T 15 B
LED201 ~ 207 2370 0630 LED LN282RPX-(TX3) 7 B
SW201 3412 1008 SWITCH/SLIDE SSB-22KP 1 B
SW202 ~ 214 3412 0903 SWITCH/TACT EVQ-21405R 13 B
VR201 2765 0952 POTENTIOMETER EWA-NAXCH1B23 1 A
4 6925 9200 PCB/ASSY (CN2) M440475*1 1 B
Keyboard unit
5 6906 8554 KEYBOARD UNIT M111412D*2 1 C
6 6925 9210 PCB/ASSY (KY1M) M140591*1 1 B
7 6925 9220 PCB/ASSY (KY2M) M240655*1 1 B
8 6925 9230 PCB/ASSY (KY3M) M140592*1 1 B
9 6921 6290 KEY/WHITE (BE) M311948*3 15 A
10 6921 6270 KEY/WHITE (CF) M311948*1 14 A
11 6921 6280 KEY/WHITE (D) M311948*2 7 A
12 6921 6300 KEY/WHITE (G) M311948*4 7 A
13 6921 6310 KEY/WHITE (A) M311948*5 7 A
14 6921 6320 KEY/WHITE (SA) M311948*6 1 B
15 6921 6330 KEY/WHITE (SC) M311948*7 1 B
Notes: Q – Quantity per unit
R – Rank
— 21 —
