— 7 —
Message on LCD
6. LCD check
1 Press “TONE” button.
2 Press “TONE” button.
*Pip sound must be audible.
The display must be changed to turn on all dots.
3 Press “TONE” button.
The display must be changed to no display.
4 Press “TONE” button.
The display must be changed to pattern 1 dot matrix.
5 Press “TONE” button.
The display must be changed to pattern 2 dot matrix.
6 Press “TONE” button.
The display must be changed to pattern 1 characters.
7 Press “TONE” button.
The display must be changed to pattern 2 characters.
8 Press “TONE” button.
The display must be changed to as remark.
7. AC Adaptor check
1 Press “SONG BANK” button.
OK sound must be audible.
8. APO check
1 Press “STOP” button.
* Go out from TEST mode (Power off).
* The LCD turns off.
DIAGNOSTIC PROGRAM IS FINISHED.
LCD
TEST
P=AC ADP

Casio CTK-2300 Specifications

General

Keys	61
Polyphony	48
Tones	400
Rhythms	150
Display	LCD
Dimensions	946 x 307 x 92 mm
Weight	3.4 kg
Touch Response	No
Sound Source	AHL
Auto Accompaniment	Yes
Built-in Songs	110
Lesson Function	Yes
Metronome	Yes
Sampling Function	Yes
Key Transpose	Yes
Speakers	10 cm x 2
Amp Output	2W + 2W
Power Supply	AC adapter or 6 AA batteries
Digital Effects	Reverb (10 types)
Tuning Control	A4 = 415.5 to 465.9 Hz
Input/Output Terminals	Headphones/Output, USB
Included Accessories	Music stand
