Item Code No. Parts Name Specification Q R
Main PCB
1 6926 7070 PCB/ASS'Y (MA1M) M240832*1 1 B
LSI1 2012 5603 LSI/MC (CPU) MSM6755B-17 1 A
LSI2 2012 5611 LSI/MASK-ROM UM23C2101M-7384/Q 1 A
LSI3 2012 5935 LSI/LCD DRIVER KS0066U-10B 1 A
IC1 2012 1883 IC/MOS (RESET IC) RN5VD40AA-TR 1 B
Q1,Q2 2252 1239 TRANSISTOR/CHIP 2SC4081T106Q 2 C
Q3 2250 1169 TRANSISTOR/CHIP 2SA1576AT106S 1 C
VR1 2775 0994 POTENTIOMETER EVN-D6AA03B53 1 C
X1 2590 2100 OSCILLATOR/CERAMIC CSACV20.00MX040-TC 1 C
Sub PCB
2 6926 7060 PCB/ASS'Y (MA2,3M) M140748*1 1 B
IC101 2114 2891 IC/LINEAR (POWER AMP) LA4598 1 A
IC102 2252 1248 IC/PHOTOCOUPLER HCPL-261A 1 B
Q101 2250 1585
TRANSISTOR
2SD1858TV2Q 1 C
Q102 2250 0168 TRANSISTOR 2SA854SR-TP-T 1 C
Q103 - Q105 2220 1409 TRANSISTOR 2SC1740SR-TP-T 3 C
D101 2390 1323 DIODE/SHOTTKY RB100A-T32-T 1 X
D102 2390 3018 DIODE 1T2 1 X
D103 2360 2044 DIODE/ZENER MTZJ6.2A-T77-T 1 C
D104 - D113 2390 1344 DIODE 1SS133T-77-T 11 X
J101
3612 0665 JACK/PHONE YKB21-5006
1C
J102
3501 7049 JACK/POWER HEC2305-01-330
1C
J103 3501 4816 JACK/DIN YKF51-5051 1 C
Keyboard PCBs
3 6926 7050 PCB/ASS'Y (KY1,2M) M140749*1 1 C
D701 - D749 2301 0101 DIODE 1S2473T-77-T 49 X
Mechanical Parts
4 3831 0665 SPEAKER 10G42AFA 2
B
5 3335 6691 LCD LD-B10272A 1 B
6 6926 7200 RUBBER/INTERCONNECTOR M440584-2 2 C
7 6909 5890 SWITCH/SLIDE CSB-12D 1 C
8 6921 5031 KNOB M311859-1 1
C
9 6926 7210 RUBBER/BUTTON M240796-1 1 C
10 6926 7220 RUBBER/BUTTON M240797-1 1 C
11 6926 7230 RUBBER/BUTTON M240798-1 1 C
12 6926 7240 RUBBER/BUTTON M240799-1 1 C
13 6922 2720 KEY SET/LT WHITE M312118*1 3
B
14 6922 2730 KEY SET/LT WHITE
M312118*2
1B
15 6922 2740 KEY SET/LT BLACK 10P M111726-1 2
B
16 6906 9191
RUBBER/CONTACT
M240549A-2 3
C
17 6906 9201
RUBBER/CONTACT
M240550A-2 1
C
18 6926 7270 PANEL/DISPLAY M340789-1 1
C
19 6925 4500 COVER/BATTERY M340528*1 1 C
Accessory
6926 7290 STAND/NOTE M140719-1 1
C
Notes: Q Ð Quantity per unit
R Ð Rank
Ñ 15 Ñ
