— 10 —
7. Remove 2 screws, the volume slider, and then the PCB ASSY (CN4M).
8. Remove 6 screws and then the LCD ASSY (LCD1M).
Note: Tighten the screws in the order from 1 to 6 when reassembling.
Screws
Screws
Volume slider
1
2
3
4
5
6
