— 11 —
N Item Parts code Parts name Specification Q
Price
Code
R Remarks
Main PCB
N 1 10238296 PCB ASSY/MAIN TK-RJM506723*001 1 A
IC11 10158805 IC RH5RL33AA-T1-FA 1 C
IC13 10159723 IC RN5VD28AA-TR-FA 1 C
IC5,IC6 10116986 IC SN74AHCT1G08DCKR 2 C
IC7 10197555 IC TC7SZ14FU(TE85L.F) 1 C
L4 10158809 COIL DLP31SN221SL2L 1 X
L2,L3,L5 10095204 FERRITE BEAD BLM18AG102SN1D 3 X
L1 10122963 FERRITE BEAD BLM21AG102SN1D 1 X
Q3 10153685 FET 2SJ346(TE85L.F) 1 X
Q1,Q2 10202670 TRANSISTOR KTA2014-GR-RTK/P 2 X
X1 10211946 RESONATOR SSM1200000F17F5FZ8 1 X
Keyboard PCB
N 2 10238298 PCB ASSY/KYA TK-RJM503929*003 1 C
D701-761 10108141 DIODE 1SS133TP 61 AA X
Keyboard unit
3 69254940 KEY SET/WHITE/CB M340503*1 4 C
4 69254950 KEY SET/WHITE/CS M340503*2 1 C
5 69222740 KEY SET/BLACK 10P M111726-1 2 AQ C
6 69222750 KEY SET/BLACK 5P M111726-2 1 AH C
7 10163902 RUBBER/CONTACT RJM503854-001V01 4 B
8 10163903 RUBBER/CONTACT RJM503855-001V01 1 B
Panel unit
N 9 10236593 PLATE/DISPLAY RJM506511-001V01 1 C
N 10 10236594 RUBBER/KEY/A RJM506512-001V01 1 C
N 11 10236595 RUBBER/KEY/B RJM506513-001V01 1 C
N 12 10236596 RUBBER/KEY/C RJM506514-001V01 1 C
N 13 10236597 RUBBER/KEY/D RJM506515-001V01 1 C
N 14 10236598 RUBBER/KEY/E RJM506516-001V01 1 C
N 15 10236599 RUBBER/KEY/F RJM506517-001V01 1 C
16 10199714 KNOB/SLIDE RJM503803-002V01 3 AB C
17 69270510 CONTACT/SLIDE CSB-08D 3 AD B
N 18 10228219 SPEAKER C10JB25 2 C
N 19 10243428 COVER ASSY/BATTERY TK-M340884*020 1 B
20 10078118 CONNECTOR M440863-003V01 2 AB C
N 21 10238082 LCD TR6040N 1 C
22 69271080 TERMINAL/BATTERY (+) M440112-1 1 AB X
23 10008078 TERMINAL/BATTERY (-) M440002A-1 1 AA X
24 69271060 TERMINAL/BATTERY M440676-1 2 AA X
25 69271070 TERMINAL/BATTERY M440677-1 3 AA X
N 26 10238295 PCB ASSY/CNA1 TK-RJM506721*001 1 B
N D101 10236646 LED 1154HD-B5/12.5-90 1 C
Notes: N- New parts
Q-Quantity used per unit
