Casio CTK-710 Service Manual

— 12 —
N Item Parts code Parts name Specification Q
Price
Code
R Remarks
IC100 10189501 IC LA4227-E 1 C
IC104,IC105 10211950 IC NJM2068M-D(TE1) 2 C
J100 10206816 JACK JY-6314*01-130 1 C MIC JACK
J101 10213695 JACK JY-6316*01-070 1 C PHONE JACK
J102 10088189 JACK DS-240A2-383V4H 1 C DC JACK
J103 10206815 JACK JY-6314*01-030 1 C SUSTAIN JACK
L101 10206672 COIL R2318-RB53856396NP 1 X
L100,L102,L103 10206680 COIL R2318-RB53856397NP 3 X
TH100 10080368 THERMISTOR MF11-103K 1 X
VR100 69304870 VARIABLE R EVND8AA03B53 1 C
Refurbish
N R-1 10236647 CASE/UPPER RJM506510-001V01 1 BZ C
N R-2 10238297 CASE ASSY/MIDDLE TK-RJM503916*005 1 C
R-3 10163935 PLATE/LOWER/A RJM503801-001V01 1 AE C
R-4 10163936 PLATE/LOWER/B RJM503802-001V01 2 AB C
R-5 69226920 RUBBER/FOOT M41361-6 5 AA C
Accessories
- 69208690 STAND/MUSIC M311760-1 1 AL C
- 10083548 BATTERY R6UW/2STA 3 AC C
- 10196868 CD ROM USB12CDROMWL1A 1 C
N 10236646 LABEL/RATING RJM504373-005V01 1 X
Notes: N- New parts
Q-Quantity used per unit

Casio CTK-710 Specifications

General

Number of Keys	61
Rhythms	100
Display	LCD
MIDI	Yes
Auto Accompaniment	Yes
Touch Response	No
Song Memory	No
Lesson Function	Yes
Power Supply	AC Adaptor or Batteries
