Casio DT-X200-10E Service Manual

– 25 –
DT-X200/DT-X8
5-4-3. List of test items
The following table shows the test items.
Degree of importance:
A: Essential
(A): Essential when the part is replaced
B: As required
Test P.: Test Program, OS Ap: OS Application
Category No. Item Degree Program used Remarks
Initial settings
1
Registration and confirmation of
product ID
(A) OS Ap
IDCHK_PY052.exe
IDSET_PY052.exe
Perform before
starting a test.
2 Laser Calibration (A) Test P All Test MENU-3
Barcode (User's Guide)
*1D Laser model only
Function test
1 RAM A Test P All Test MENU-1
2 ROM A Test P All Test MENU-1
3 EEPROM A Test P All Test MENU-1
4 ADC-Sensor A Test P All Test MENU-4
5 KEY-1 A Test P All Test MENU-1
6 KEY-2 A Test P All Test MENU-1
7 Battery Cover SW (Standard) B Test P All Test MENU-1
8 Touch Panel A Test P All Test MENU-1
9 microSD card A Test P All Test MENU-4
10 LCD A Test P All Test MENU-2
11 LCD Backlight B Test P All Test MENU-2
12 Operation LED B Test P All Test MENU-2
13 Charge LED(USB) B Test P All Test MENU-2
USB and Charging Unit,
AC Adaptor, USB Cable
14 Speaker A Test P All Test MENU-2
15 Key Backlight A Test P All Test MENU-2
16 Audio(Rec & Rep) A Test P All Test MENU-3
17 Vibrator A Test P All Test MENU-4
18 Laser Barcode Read A OS Ap
*1D Laser model only
19 2D Scanner Dust Check A Test P All Test MENU-3
White paper
*2D Scanner model only
20 2D Scanner Barcode Read A OS Ap *2D Scanner model only
21 Full Range Imager I/F (UART) A Test P All Test MENU-7 *Full Range model only
22 Full Range Imager Barcode Read A OS Ap *Full Range model only
23 Howling Check A Test P All Test MENU-5
24 NFC Tag ID Read A Test P All Test MENU-7 *NFC model only
Communication
test
1 Cradle I/F(USB-Host) B Test P All Test MENU-4
Ethernet Cradle,
USB memory
2 Cradle I/F(USB-Client) A OS Ap
Ethernet Cradle, USB
Cable,
AC Adaptor,
Test PC
3 W-LAN A OS Ap W-LAN access point
4
Bluetooth Class2
(Communication)
A OS Ap
BTServer.exe
BTLineTest.exe
Opponent DT-X200/DT-
X8
Voltage
measurement
1 Low Voltage Detection B Test P All Test MENU-3
DC power supply,
DC voltage meter,
DC ammeter
Current
measurement
1 Run Mode Current B Test P All Test MENU-6
2 Sleep Mode Current B Test P All Test MENU-6
3 Laser/Linear Current B Test P All Test MENU-6
4 2D Imager Current B Test P All Test MENU-6
5 W-LAN Current B Test P All Test MENU-6
6 Full Range Imager Current B Test P All Test MENU-6
Completion 1 Delete Test Program A OS Ap zDiagDelete.exe
