– 42 –
DT-X200/DT-X8
3. W-LAN
1. Preparation
Connect equipment as follows:
Access Point
Wireless
Transmission
2. Operation
No. Operation Display Test Details
1
Select
“
Settings” -
“
Control
Panel” -
“
WLANPower”.
Check the checkbox “WLAN
Power Enable” and click
“OK” to supply power to the
integrated WLAN module.
The Indicator 2 (on the right side
of DT-X200/DT-X8) starts fl ashing
in orange.
2
Select
“
Programs” -
“
Communication” -
“
NetSearch”.
Then, input “SSID”, “IP
address”, etc. of the target
access point.
Carry out SS wireless test using
“Ping” and “Signal” functions.
Check if the test results are
acceptable comparing with a good
DT-X200/DT-X8.
To Next Page
