Casio DT-X200-10E Service Manual

— 77 —
DT-X200/DT-X8
1 DT-X200-10E
2 DT-X200-11E
3 DT-X200-20E
4 DT-X200-21E
5 DT-X200-41E 6 DT-X8-10C-CNV
7 DT-X8-20C-CNV
1234567
RN Item Code No. Parts Name Specification
Q'ty
LOWER-CASE-UNIT
N 49 10500576 CASE-SUBASSY/LOWER RJC505172*003V05 1111 11C
N 49 10500582 CASE-SUBASSY/LOWER RJC506030*003V02 1 C
N 50 10500578 SUBASSY/TRIGGER/L RJC505250*003V02 1111111C
N 51 10500579 SUBASSY/TRIGGER/R RJC505253*003V02 1111111C
52 10385347 TAPE/TRIGGER RJC505256-001V01 2222222X
53 10385374 PLATE/TRIGGER RJC505258-001V01 2222222X
54 10303440 LOCK/BATTERY RJC503747-001V01 2222222C
55 10303517 RING/BATTERY/LOCK RJC503929-001V01 2222222X
N 56 10500574 HOOK/BATTERY/L RJC505259-003V02 1111111C
N 57 10500575 HOOK/BATTERY/R RJC505260-003V02 1111111C
58 10385384 TAPE/DOUBLE/BELT/A RJC505461-001V01 1111111X
60 10385367 BLIND/BC RJC505446-001V01 1111111X
61 10391090 TAPE/DOUBLE/BLIND/BC RJC505447-001V02 1111111X
62 10385343 COVER/BELT RJC505248-001V01 1111111C
63 10408263 BUTTON/RESET RJC506004-001V01 1111111C
64 10397197 COVER/RESET RJC505225-001V02 1111111C
65 10422003 BUTTON/DET RJC506294-001V01 1111111C
66 10385341 PACKING/PL RJC505219-001V01 1111111C
67 10390581 SPACER/CONNECTOR/KEY RJC505200-001V02 1111111X
68 10385339 SHEET/BATTERY RJC505215-001V01 1111111X
69 10385342 PACKING/EXT RJC505222-001V01 1111111X
N 70 10500577 CAP/microSD RJC505140-003V02 1111111C
71 10387982 TAPE/ESD RJC505543-001V01 4444444X
72 10288956 TAPE/CONNECTOR/B RJC503687-002V01 1111111X
N 73 10469745 CABLE/FPC/TRIGGER RJC507000-001V01 1111111C
74 10391410 SPACER/PCB-CAP RJC505674-001V01 1 1 1 1 1 1 1 X
87 10408947 ANTENNA/NFC RJC505120-001V02 1 1 1 C
88 10408948 TAPE/DOUBLE/NFC RJC505233-001V02 1 1 1 X
44 10288955 TAPE/CONNECTOR/A RJC503687-001V01 1 1 1 X
94 10413279 BLIND/NFC RJC506124-001V01 1 X
S1 10245664 SCREW RJC502686-001V01 4 5 4 5 5 4 4 X
S8 10385301 SCREW RJC504463-003V01 1 1 1 1 1 1 1 X
S9 10339619 SCREW RJC504463-001V01 2 2 2 2 2 2 2 X
BUNDLED ITEMS
75 10385360 HAND STRAP RJC505382-001V01 1111111X
76 10385355 PEN (STYLUS) RJC505313-001V01 1111111X
N 77 10500650 PEN CODE PEN-CODE-PY052VA 1111111X
78 10403543 AC ADAPTOR SA115B-05U-HK2 1111111X
79 10215971 AC CABLE/EU INQ.361(2) 11111 X
79 10391989 AC CABLE/CN INQ.1381(2)-GA 1 1 X
80 10387631 USB CABLE GL-080 1111111X
TOOLS
81 94900080 SPECIAL SCREW DRIVER D3LU0X88G 2.0X20 1111111A
82 10195882 LEAD FREE SOLDER SR-34LFM-48 (0.8MM) 1111111B
10409754 FILM/TP RJC506040-001-V01 1111111X
10442843 RFID TAG P3D04-L1A5 1 1 1 X
