Casio DT-X200-10E Service Manual

— 76 —
DT-X200/DT-X8
1 DT-X200-10E
2 DT-X200-11E
3 DT-X200-20E
4 DT-X200-21E
5 DT-X200-41E 6 DT-X8-10C-CNV
7 DT-X8-20C-CNV
1234567
RN Item Code No. Parts Name Specification
Q'ty
26 10394354 EXT-UNIT RJC505404*001 TK 1111111A
N 27 10530599 WLAN-UNIT/2.4G RJC507591*001 TK 1111111C
28 10073157 BATTERY VL2330/1VC 1111111C
29 10376933 SUBASSY/WIRE RJC505093-001V01 1111111C
30 10289904 TAPE/DOUBLE/SBAT RJC503702-001V01 1111111X
31 10394356 TR-IC-UNIT RJC505403*001 TK 1111111C
N32
10512107
LASER-ASSY RJC507392*001 TK 1 1 1 C
32-1 10385338 SHEET/LAER RJC505214-001V01 1 1 1 X
S5 10215901 SCREW S-PAMA-2X4NIME 2 2 2 X
N 33 10512108 LASER-UNIT RJC507393*001 TK 1 1 1 A
N 34 10512109 2D-ASSY RJC507394*001 TK 1 1 1 C
S6 10215739 SCREW S-BDB0-2.3X4NI 2 2 2 X
N 35 10512110 2D-UNIT RJC507395*001 TK 1 1 1 A
36 10397277 CASE/INNER RJC505123-001V02 1111111C
37 10385337 SPRING/COIL RJC505207-001V01 4444444X
N 38 10490226 MOTOR/VIBRATION L5.5-V7AD-CA25-A 1111111C
39 10385327 HOLDER/SBAT RJC505213-001V01 1111 11C
40 10397280 TAPE/DOUBLE/SUP-FPC RJC505249-001V02 1111111X
41 10389680 SPACER/SBAT RJC505216-001V02 1111111X
42 10390582 TAPE/DOUBLE/SP-FPC RJC505210-001V02 1111111X
43 10288956 TAPE/CONNECTOR/B RJC503687-002V01 3344334X
44 10288955 TAPE/CONNECTOR/A RJC503687-001V01 2211221X
45 10407618 SPACER/PLT/SC RJC506017-001V01 2222222X
46 10397038 SPACER/BATTERY-PLATE RJC505757-001V01 1111111X
47 10392853 BLIND/2D RJC505686-001V01 1 1 1 X
83 10463432 NFC-UNIT RJC506368*001 TK 1 1 A
83 10463433 NFC-UNIT RJC506368*002 TK 1 A
84 10409912 SHEET/EMI/NFC RJC506109-001V01 1 1 X
85 10363796 TAPE/CONNECTOR/G RJC503687-007V01 2 2 2 X
86 10400389 CABLE/FPC/NFC RJC505165-001V01 1 1 1 C
90 10390038 SHEET/HEAT RJC505638-001V01 1 C
91 10416367 SPACER/FRI RJC506297-001V01 1 X
92 10517278 FRI-ASSY RJC505995*002 TK 1 A
N 93 10512111 FRI-UNIT RJC507396*001 TK 1 A
N 95 10512112 WLAN-UNIT/5G RJC507407*001 TK 1111111X
N 96 10288959 TAPE/CONNECTOR/C RJC503687-003V01 1111111X
N 97 10507429 TAPE/LCD RJC507490-001V01 1111111X
N 98 10497515 SPACER/2D RJC507382-001V01 1 1 1 X
N 99 10497524 TAPE/DOUBLE/2D RJC507408-001V01 1 1 1 X
N 100 10507430 CUSHION/2D-FPC RJC507482-001V01 1 1 1 X
S1 10245664 SCREW RJC502686-001V01 5 7 5 7755X
S7 10344574 SCREW RJC504531-001V01 6 6 8 8768X
N S10 10102278 SCREW S-BDB0-2X6NI 2 2 2 X
N S11 10245662 SCREW RJC502609-002V01 1 1 1 1111X
