Casio KL-7000 Service Manual And Parts List

— 10 —
PR-1 (Normal printing result)
PR-2 (Normal printing result)
Table-5(2/2)
Figure-9
Figure-10
Check item Operation Display Note
KEY CHECK
(3 KEY)
Press the key according to
what is appeared on the LCD.
Press any key after last key
check to return the main menu.
RANK CHECK
(4 SW)
Check the rank of the thermal
head employed in the unit.
(RANK = A ~ D)
PRINT CHECK-1
(5 PR1)
Refer to the following figure-7.
PRINT CHECK-2
(6 PR2)
Refer to the following figure-8.
VP CHECK
(7 VP)
TCON signal from CPU is H,
voltage VP is applied to the
thermal head and stepping
motor.
ALL ITEM CHECK
(0 ALL)
The 5 check items are
proceeded automatically by
pressing any key, according to
the following order.
RAM---LCD---KEY---SW---PR1
3
1
4
RANK X
5
NOW
PRINTING
6
NOW
PRINTING
7
Vp ON
0
