E-24
Number of Lines with
Frame
24/18mm
Up to 2
12/9/6mm
1
Part 8 Using Frames
The printer comes with a selection of built-in frames that you can use in your
tape labels. See page E-38 for a list of frames that are available.
Example
1. Input the text you want.
2. Press FRAME.
3. Use the cursor keys to select the frame you want, and then press SET.
• Here we will select
.
4. Use x and z to select PRINT, and then press SET .
This will display a screen for specifying the number of copies.
5. Specify the number of copies and then press SET to start printing.
• The text effect setting is not applied when printing with a frame.
• The frame function cannot be used when there are a block mark input. If you
want to use the frame function, delete the block mark.
Part 9 Layout Printing
Using Layout Printing
The printer comes with a Layout Printing feature with preset formats for CD/
DVD labeling, video tape labeling, and other applications.
Example
1. While the text input screen is displayed, press PRESET.
2. Use
z and x
to select LAYOUT and then press SET.
3. Use
z and x
to select NEW and then press SET.
ALY
OUT
–––
–
C/D
V
D
D
V
SH
m
ni
i
VD
––––
4.
Use z and x to select the type of label you want to print and then press SET.
Here we will select “CD/DVD”.
Frames and the Number of Lines
The number of lines that can be printed with a frame depends on the width
of the tape.
To Next Page
