DL-1841A(S type) Germany, Europe, Other countries
N Item Code No. Parts Name Specification Qt'y
Price
code
Rank
1 1012 7601 CASE/MAIN RJE500670-001V01 1 BC X
N 2 1012 7602 PLATE/T.C ED21-16 RJE500672-001V01 1C
3 5500 0878 ROLLER/DELRIN DR-19B2 2 AP B
4 10259120 LEVER ASSY/HOOK RJE502182*001V01 1 AA C
5 1012 7603 AXIS/HOOK LEVER ED21 RJE500674-001V01 1 AA C
6 1008 0393 SPRING/LOCK ED16 RJE500007-001V01 1 AA C
7 6246 6522 SPRING/PRESS ED14 E412137-1 1 AA C
8 6246 6529 RUBBER/ED14 E412136-1 5 AD C
SCREW 4X25 ZMC-3 1 X
NUT 4 ZMC-3 1 X
NUT 6 ZMC-3 2 X
WASHER 11.5X6.5X0.8 2 X
SCREW 3X8 ZMC-3 4 X
SCREW 3X20 ZMC-3 2 X
9 1008 7969 SOLENOID SUB ASSY RJE500126*002V01 1 AW B
10 1012 7599 DRAWER/ED21-16 RJE500671-001V01 1 AZ C
N 11 1019 0957 PLATE/PARTITION S-GR RJE500214-002V02 2 C
N 12 1019 0960 BILL HOLDER SUB ASSY E341290*002V02 3 C
13 1007 9063 SPRING/BILL HOLDER ED16 E441357-1 3 AA C
14 1008 0123 PLATE/BILL HOLDER FIX ED16 E341289-1 1 AD X
SCREW 3X5 NI 3 X
15 5500 0878 ROLLER/DELRIN DR-19B2 2 AP B
NUT 6 ZMC-3 2 X
16 5440 0287 RIVETS/COLD HEADED 5X26 1 AA C
17 5580 1452 CS FIX CTSW-5 1 AA C
N 18 1019 0976 CASE/COIN E264 RJE500212-002V03 1 C
N 19 1019 0977 SEPARATER/COIN E264 RJE500213-002V02 4 C
20 1012 0527 LOCK/CYLINDER CL-16C 1 AS C
SCREW 3X8 ZMC-3 3 X
21 COVER/TOP E270-16 RJE500753-002V02 1 X
SCREW 3X6 ZMC-3 3 X
22 LABEL/DL-1841A E341256-48 1 X
N 1008 6042 SEPARATER/BILL E272 RJE500103-001V01 1 C
