Casio PCR-262 Service Manual

DL-2796A(M type) Canada
N Item Code No. Parts Name Specification Qt'y Price Rank
code
1. MAIN CASE BLOCK
1 10078897 CASE/MAIN E140494-1 1 BS X
2 55000619 ROLLER/DELRIN DR-19B1 2 AG B
3 10079066 NUT 6 ZMC-3 2 AA X
4 10078764 LEVER/HOOK E341286-1 1 AA C
5 10078754 AXIS/HOOK LEVER E341241-1 1 AA C
SCREW 3X8 ZMC-3 4 X
6 10080393 SPRING/LOCK RJE500007-001 1 AA X
7 62465010 SPRING/PRESS E412069-1 1 AA X
8 62466529 RUBBER/PAD E412136-1 4 AD X
9 10080191 SOLENOIDO SUB ASSY E341301*4 1 BC B
10 10078901 COVER/UPPER E140498-1 1 AN X
11 10078759 RAIL/MLED18 E240841-1 1 AQ C
12 10078760 RAIL/MRED18 E240842-1 1 AQ C
13 10080450 RUBBER/DUMPER RJE500005-001 4 AB X
SCREW 4X10 ZMC-3 6 X
14 10079068 WASHER 6X13X1.0 ZMC-3 2 AA X
15 COVER/TOP RJE500742-002V03 1 X
SCREW 3X8 NI 3 X
LABEL/DL-2778A E341256-50 1 X
10135773 WEIGHT/COUNTER ED18 RJE500819-001V01 1 AZ X
SCREW 4X10 ZMC-3 2 X
2. UPPER DRAWER
16 10078898 DRAWER/UPPER E140495-1 1 AT C
17 10078899 PANEL/FRONT E140496-1 1 AP X
18 10078740 PLATE/STP E441288-1 1 AA C
19 10078741 LEVER/STP E341242-1 1 AA C
20 10078755 HOLDER/STP E341243-1 1 AA C
SCREW 3X8 ZMC-3 2 X
SCREW 3X10 NI 2 X
3. LOWER DRAWER
21 10078903 DRAWER SUB ASSY/LOWER E341274*1 1 BJ X
22 55000619 ROLLER/DERULIN DR-19B1 2 AG B
23 52000106 RIVET 5X30 1 AA X
24 62465030 SPRING/EARTH E412092-1 1 AA X
25 10079060 LOCK/CYLINDER CL-16 1 BA C
26 10078900 PANEL/FRONT E140497-1 1 AV X
SCREW 3X10 NI 2 X
27 54400399 WASHER 6X13X1.0 ZMC-3 2 AA X
N 28 10110736 CASE/BILL COIN RJE500367-001V01 1 BE C
29 10106268 SEPARATER RJE500219-001V01 3 AA C
N 30 10190960 BILL HOLDER SUB ASSY E341290*002V02 4 AB B
31 10079063 SPRING/BILL HOLDER E441357-1 4 AA C
32 10079064 BRACKET/BILL HOLDER E240845-1 1 AD X
SCREW 3X8 ZMC-3 3 X
SCREW 3X5 NI 4 X
