— 7 —
FPC
Hooks
Screws
Screws
Spacer
Common sheet
Chassis
FPC
■ Disassembling the keyboard unit
10.Remove the FPC as well as the four screws, and then the keyboard unit.
11. Remove the two screws and then disassemble the keyboard unit.
