Casio QW-2812 User Manual

5. PARTS LIST: MODULE QW-2812
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ---------------------------------------- Very Important
B Rank ---------------------------------------- Important
C Rank ---------------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basi
s
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name Specification Applicable Q R
MODULE/WITHOUT MOVEMENT QW-2812YC-01 WVH-500D-7A
< The module QW-2812 is "built-in t
yp
e" which is assembled directl
y
to
the case, therefore the module as the s
p
are
p
arts is not available. >
1 1013 0239 LCD S2815-01THP
QW-2812YC-01
1A
2 1013 5055 EL YEL-2815-A-00
QW-2812YC-01
1A
3 7640 7379 PCB ASS'Y RJQ517221*001V01TK
QW-2812YC-01
1A
4 7110 6336 OSCILLATOR/CRYSTAL CFS-145LM07
QW-2812YC-01
1B
5 1006 5657 BATTERY/STORAGE CTL1616
QW-2812YC-01
1B
6 1009 7687 CUSHION 2549 Q470646-1
QW-2812YC-01
1C
7 1008 2184 CUSHION 2709-2 Q469841-1
QW-2812YC-01
1C
8 1013 5052 CUSHION 2815 RJQ515128-001V01
QW-2812YC-01
1C
9 1013 5138 HOLDER RJQ514979-001V01
QW-2812YC-01
1C
10 1014 2487 INTERCONNECTOR RJQ517008-001V01
QW-2812YC-01
1C
11 1014 0782 LABEL RJQ517198-001V02
QW-2812YC-01
1C
12 7228 0364 POLE Q421168A-1
QW-2812YC-01
1C
13 7207 8349 SCREW 13 Q47608A-1
QW-2812YC-01
1B
14 7207 8470 SCREW 465 Q48694B-1
QW-2812YC-01
4C
15 1013 4221 SHEET/INSULATION
RJQ515739-001V01 QW-2812YC-01
1C
16 1013 5139 SHEET/INSULATION RJQ515079-001V01
QW-2812YC-01
1C
17 1013 5134 SPACER RJQ514651-001V02
QW-2812YC-01
1C
18 1000 3815 SPRING/COIL 1910-1 Q465481-1
QW-2812YC-01
2B
19 1008 2129 SPRING/COIL 2512-2 Q469640-1
QW-2812YC-01
2B
20 1013 5135 SUPPORTER/PCB ASS'Y RJQ514652-001V03
QW-2812YC-01
1C
21 1013 5136 TERMINAL/BATTERY
(
+
)
RJQ514658-001V02
QW-2812YC-01
1C
For the
p
rices and minimum order/su
pp
l
y
q
uantities of the above
p
arts, refer to the Parts Price List P.P.L.-603.
Notes: Q - Used quantity
R - Rank
— 11 —
