SE-S400/SE-S800/PCR-T500/PCR-T520/SE-C450
SE-S3000/SE-S900/PCR-T2300/PCR-T2400/SE-C3500
K. KEY
BLOCK
K-1.
Disconnect one FPC.
K-2.
Undo eight screws.
K-3.
Remove the KEY BLOCK.
NOTES ON
ASSEMBL
Y
Secure the FPC.
FPC
All "S1" screws
L. SWITCH
ASSY/MODE
KEY
L-1.
Undo one screw
.
L-2.
Remove the SWITCH
ASSY/MODE KEY
.
SWITCH ASSY/MODE
KEY
Screws (S1)
19
21
