SE-S400/SE-S800/PCR-T500/PCR-T520/SE-C450
SE-S3000/SE-S900/PCR-T2300/PCR-T2400/SE-C3500
PARTS LIST
1 DL-1336
2 DL-1846
12
1 10452713
COVER/TOP RJE503983-009V01 1 1
X
2
10238194
PLATE/FRONT RJE501359-003V01 1 1 C
3
10292206
CASE/MAIN RJE500670-003V04 1 1 C
4
10078787
SUB ASSY/SOLENOID E341255*1 1 1 C
5 10267909 SPRING/PLUNGER RJE502245-001V01 1 1 C
6 10167366 RUBBER/PAD RJE501204-001V01 5 5 C
7 10194207 SPRING/PRESS E412137-001V02 1 1 C
8 10201068 LOCK/SPRING RJE500007-001V02 1 1 C
9 10127603 AXIS/LEVER HOOK RJE500674-001V01 1 1 C
10 10236805 LEVER/HOOK E341286-001V03 1 1 C
11 10384548 ROLLER/DELRIN PB-19B2 4 4 C
12
10431048
CASE/BILL COIN RJE500671-009V01 1 X
12 10292207 CASE/BILL COIN RJE500671-005V03 1 X
13 10298552 SEPARATER/COIN RJE500213-002V03 4 4 C
14 10298558 CASE/COIN RJE500212-002V04 1 1 C
15
10231347
SUB ASSY/BILL HOLDER RJE501337*001V03 1 X
16
10231349
SUB ASSY/BILL HOLDER RJE501337*002V03 1 X
17 10298553 SEPARATER/COIN RJE500214-002V03 2 C
18 10276626 SPRING/BILL HOLDER E441357-001V03 4 3 X
19 10120527 LOCK/CYLINDER CL-16C 1 1 C
20 10238184 RIVET T-CRTP-5X26Z3 1 1 X
21 55801452 CS FIX CSTW-5 1 1 X
S1 SCREW (3±6) 3X6 ZMC-3 3 3
S2 SCREW (3±8) 3X8 ZMC-3 4 4
S3 SCREW (3±18) S-PAST-3X18Z3 2 2
S4 SCREW (3±8) S-PAB0-3X8Z3 3 3
Specification
Q'TY
RN Item Code No. Parts Name
We recommend to purchase screws locally.
e.g. SCREW (3
8)
Diameter: 3 mm, Length: 8 mm
