Casio SE-S300 Service Manual

— 71 —
1 DL-2800
2 DL-2801
3 DL-2802
4 DL-2803
5 DL-2804
6 DL-2805
7 DL-2806
8 DL-2807
9 DL-2432
10 DL-2433
1 2 3 4 5 6 7 8 9 10
1 10304443 SUB ASSY/BOX RJE502373*001V08 1 1 1 1 1 1 X
1 10304445 SUB ASSY/BOX RJE502373*002V08 1 1 1 1 X
2 10203587 CHASSIS/BOTTOM RJE501384-001V01 1 1 1 1 1 1 1 1 1 1 X
3 10122202 LOCK ASSY RJE500567*003V01 1 1 1 1 1 1 A
3 10203176 LOCK ASSY RJE500567*004V01 1 1 1 1 A
4 55000619 ROLLER/DELRIN DR-19B1 2 2 2 2 2 2 2 2 2 2 B
5 10194208 RUBBER/DUMPER RJE500005-001V02 4 4 4 4 4 4 4 4 4 4 X
6 10223071 SUB ASSY/DRAWER E341274*002V04 1 1 1 1 1 1 1 1 1 1 C
7 55000619 ROLLER/DELRIN DR-19B1 2 2 2 2 2 2 2 2 2 2 B
8 10201065 SPRING/EARTH E412092-001V02 1 1 1 1 1 1 1 1 1 1 C
9 10203374 LOCK/CYLINDER CL-23 1 1 1 1 1 1 1 1 1 1 C
10 10215645 PANEL/FRONT RJE501385-001V02 1 1 1 1 1 C
10 10292500 PANEL/FRONT RJE501385-002V01 1 1 1 1 1 C
11 52000106 RIVET 5X30 1 1 1 1 1 1 1 1 1 1 X
12 10200516 BILL COIN CASE ASSY RJE501368*004V01 1 1 1 1 C
12 10225530 BILL COIN CASE ASSY RJE501368*006V01 1 1 1 1 C
12 10225528 BILL COIN CASE ASSY RJE501368*007V01 1 1 C
13 10230104 SUB ASSY/ BILL HOLDER E341290*002V04 4 4 4 4 4 4 4 4 5 5 A
14 10276626 SPRING/BILL HOLDER E441357-001V03 4 4 4 4 4 4 4 4 5 5 A
15 10194233 PLATE/BILL HOLDER E240845-001V02 1 1 1 1 1 1 1 1 1 1 X
16 10298565 CASE/BILL E140505-002V03 1 1 1 1 1 1 X
16 10298566 CASE/BILL RJE500367-002V02 1 1 1 1 X
17 10298559 CASE/COIN RJE500217-002V02 1 1 1 1 C
17 10298560 CASE/COIN RJE500284-002V02 1 1 C
18 10298554 SEPARATER/COIN RJE500216-002V02 6 6 6 6 B
19 10298555 SEPARATER/BILL RJE500219-002V02 3 3 3 3 3 3 3 3 4 4 B
20 10203171 CASE/FOOT RUBBER RJE500667-001V02 4 4 4 4 4 4 4 4 4 4 X
21 10167366 RUBBER/FOOT RJE501204-001V01 4 4 4 4 4 4 4 4 4 4 X
N Item
Price
code
RSpecificationParts NameCode No.
Q
