Casio SF-5300B Service Manual & Parts List

10. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
DISPLAY PCB ASS'Y
N 1 6412 2750 Display PCB ass'y DB22XX3F01M
1
1 2,730 B
(Consists of the following:)
C1~4,7,8,12,13,14 2845 1540 Chip capacitor MCH212F104ZK
8
20 4 C
C5,6 2845 1652 Chip capacitor MCH215A180JK
1
20 3 C
N LSI1 6411 6351 COF sub ass'y C312133*3
1
1 970 B
N LSI2 2011 8267 LSI CXK58257ATM-10/12L
1
1 580 B
N LSI3 2011 8274 LSI CXK58257AYM-10/12L
1
1 580 B
N LSI4 2011 9149 LSI µPD23C1001EAGZ-M04
1
1 370 B
X1 7110 0642 Crystal oscillator DT-26S
1
557B
N R3 2797 3752 Chip resistor ERJ-6GEYJ000
1
20 2 C
N R4 2797 3752 Chip resistor ERJ-6GEYJ000
1
20 2 C
R11 2791 0777 Chip resistor ERJ-6GEYJ104
1
20 5 C
N R12 2797 3857 Chip resistor ERJ-6GEAK206
1
20 2 C
KEYBOARD PCB ASS'Y
N 6 6412 2730 Keyboard PCB ass'y DB22XX3100U
1
1 790 B
(Consists of the following:)
C9,11 2803 6806 Electrolytic capacitor 10MS510M-MW
2
20 13 C
C10 2845 1540 Chip capacitor MCH212F104ZK
1
20 4 C
D1 2390 2128 Chip diode MA740-(TX)
1
10 50 C
D2 2390 0364 Schottky diode MA713-(TX)
1
10 33 C
DET1 2105 3864 CMOS IC RH5VL46CA-T1
1
10 45 C
REG1 2105 3290 CMOS IC S-81253SGUP-DIJ-T1
1
560C
J1 3501 6538 Jack HSJ1169-012010
1
556C
N R5 2797 3759 Chip resistor ERJ-6GEYJ182
1
20 2 C
R6 2797 0637 Chip resistor ERJ-6GEYJ473
1
20 2 C
R7 2797 1309 Chip resistor ERJ-6GEYJ102
1
20 3 C
R8,9 2797 1078 Chip resistor ERJ-6GEYJ101
2
20 3 C
N R20 2797 3752 Chip resistor ERJ-6GEYJ000
1
20 2 C
Q1 2259 0959 Chip digital transistor DTC114YKT-146
1
20 12 C
6-1 6409 6300 Spring Battry (+) EF01DB20102
2
20 16 X
6-2 6409 6310 Spring Battry (-) EF02DB10100
2
20 16 X
COMPONENT
N 2 6412 3110 Protection tape HGJ00008406
1
20 19 B
3 6412 3140 Heat seal FX21P250016
1
553A
N 4 6412 3120 Protection tape HGJ00008201
1
20 26 B
N 5 6412 2920 Insulation plate EL4J0002102
1
10 29 X
7 6511 7160 Cap LC120000102
1
20 17 B
8 6412 2890 Key contact rubber LADB2210000
1
1 260 C
9 6512 0730 Hinge stopper EF15DB06102
2
20 27 X
10 6412 2880 Push button FB3DB221002
1
20 13 C
11 6412 3020 Upper case (KB) FAADB221009
1
1 130 X
N 12 6412 3050 Hinge (A) FC0DB281006
1
20 26 X
13 6512 1210 Pin FC002870000
2
20 9 X
14 6512 1220 Pin (L) FC002870018
2
20 16 X
N 15 6412 2910 Hinge (B) FC0DB222002
1
20 22 X
N 16 6412 2990 Hinge blind tape HGJ00008309
1
20 22 B
N 17 6412 2940 Display plate EL5J0005103
1
1 120 B
N 17 6412 2950 Display plate (for B.O.S.S.) EL5J0005201
1
1 120 B
18 6412 3040 Upper case (DIS) FAADB222005
1
1 110 X
19 6412 3130 Heat seal FX200P40064
1
1 100 A
20 3335 5264 LCD CD792-TS
1
1 790 A
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 25 —
