— 20 —
Operation Display Note
(After a few seconds)
MEMORY 3 WR2
4 READ2
1 WR1 5 DUMP
2 READ1 6 CHKSUM
EXECUTING!!
2
( or 4 )
COMPLETE!!
128KB
DATA ERROR!!
ADDRESS CORR RAM
XXXX XX XX
KEY 1 RANDOM
2 AUTO
Press 3 on the TEST MENU.
Key check
To return to the
TEST MENU,
press .
No display
RAM error
If the "DATA ERROR"
is appeared, check
LSI2.
Operation Display Note
MEMORY 3 WR2
4 READ2
1 WR1 5 DUMP
2 READ1 6 CHKSUM
ESC
ESC
2
Key Check
Each key has its own key code. The key codes are assigned incrementally from left to right on the key
board. (Refer to the keyboard in the schematic diagrams.)
In the auto mode, the key input sequence is limited so that the keys must be pressed in the order of the
key code as mentioned above. If a key is pressed in the wrong order, the SF-5300B beeps.
