— 11 —
4.
1 Remove the screw and the earth cable.
5. Remove the two screws.
6. Remove LCD rear case.
NOTE: Be careful of the hooks when removing the LCD rear case.
7. Remove the slide knob.
2 Remove the two screws.
3 Remove the LCD ass’y.
2
1
3
Hooks
