— 63 —
[ 28 ] KEY dipsplay
[Function]
The key codes for all keys except “Esc” key which are pressed down are displayed.
The key codes are located as shown in the following figure.
Note that “RF” and “JF” do not respond when pressed down during this test.
[Operation]
Operation : 9 4 SUBTOTAL
To stop the test, press “Esc” key.
[LCD]
[Print]
No printing is done in this test.
[Location of the key code]
KEY 94
KEY#mmm
END 94
TE-7000S
90 91 92 93 94
95 96 97 98 99
RF JF 77 10 70 68 66 60 54 48 42 36 30 24 ESC
87 82 76 71 69 67 65 59 53 47 41 35 29 23 17
86 81 75 7 8 9 645852464034 28 22 16
85 80 74 4 5 6 635751453933 27 21 15
84 79 73 1 2 3 625650443832 26 14 20
83 78 72 0 11 12615549433731 25 13 19
TE-8000F
152 153 154 155 156
157 158 159 160 161
RF JF 35 30 ESC 51 60 69 78 87 96 105 114 123 132 141 150
42 39 34 29 20 50 59 68 77 86 95 104 113 122 131 140 149
41 38 33 28 19 49 58 67 76 85 94 103 112 121 130 139 148
40 37 32 27 18 48 57 66 75 84 93 102 111 120 129 138 147
10 36 31 26 17 47 56 65 74 83 92 101 110 119 128 137 146
7 8 9 25 16 46 55 64 73 82 91 100 109 118 127 136 145
4 5 6 24 15 45 54 63 72 81 90 99 108 117 126 135 144
1 2 3 14 23 44 53 62 71 80 89 98 107 116 125 134 143
0 11 12 13 22 43 52 61 70 79 88 97 106 115 124 133 142
TE-8500F
152 153 154 155 156
157 158 159 160 161
RF JF 67 76 85 94 103 112 121 130 148 42 38 33 28 ESC
50 58 66 75 84 93 102 111 120 129 147 41 37 32 27 20
49 57 65 74 83 92 101 110 119 128 146 40 36 31 26 19
48 56 64 73 82 91 100 109 118 127 145 39 35 30 25 18
47 55 63 72 81 90 99 108 117 126 144 10 34 29 24 17
46 54 62 71 80 89 98 107 116 125 143 7 8 9 23 16
45 53 61 70 79 88 97 106 115 124 142 4 5 6 22 15
44 52 60 69 78 87 96 105 114 123 141 1 2 3
43 51 59 68 77 86 95 104 113 122 140 0 11 12
14
13
To Next Page
