V-R7000/V-R7100
– 51 –
Parts List
We recommend to purchase screws locally.
e.g. SCREW (3

8)

Diameter: 3 mm, Length: 8 mm
NUT (4X0.7)

Diameter:4 mm, Thickness: 0.7 mm
1
DL-3401
Qt'y
1
1 CASE/MAIN V012K00008 1
2 9487 0975 LOCK SUB ASSY V081K00013-K1 1 C
3 9487 0976 SOLENOID SUB ASSY ZD53541 1 B
4 1907 7123 SPRING/PUSH ZD01370B 1 C
5 1907 6277 RUBBER/DAMPER
V044E00002K1
1X
6 1906 0674 CABLE ASSY ZD53544-K3 1 C
7 NYLON CLAMP NK-3N 1
8 1902 7112 GROMMET B-1 1 X
9 9487 0965 SIDE ROLLER SUB ASSY/RH ZD52817 1 B
10 9487 0966 SIDE ROLLER SUB ASSY/LH ZD52818 1 B
11 5800 0043 ROLLER/DELRIN DR-19B 4 B
12 STOPPER RUBBER ZD52831 2
13 DRAWER SUB ASSY ZD52820 1
14 9487 0967 LINK ZD52864 1 C
15 5430 0208 E-RING V042E00005-K1 1 C
16 9487 0968 UNLOCK UNIT ZD52860 1 C
17 1907 7930 SPRING/UNLOCK ZD00254 2 C
18 1906 4150 RIVET 5X30 1 C
19 5580 1452 RING/CS CSTW-5 1 C
20 9487 0969 ROLLER/DELRIN DL-19B 2 B
21 9487 0970 COVER/UNLOCK ZD52870 1 C
22 PANEL/FRONT ZD53521 1
23 PLATE/BOTTOM V094E00018 1
24 9487 0971 RUBBER/PAD K3215H 4 C
25 9487 0972 CASE/BILL V044E00003-K1 1 C
26 9487 0973 BRACKET/BILL HOLDER ZD52852 5 C
27 1902 7084 BILL HOLDER ZD02041 5 C
28 9487 0797 SPRING/BILL HOLDER ZD52853 5 C
29 CLAMP CKN-5 1
30 SPACER V112E00001 1
31 9487 0974 LOCK CYLINDER SET ZD52865 1 C
32 EARTH/PLATE V114E00003 1
S1 SCREW(4X16) M4X16 5
S2 SCREW(4X6) M4X6 1
S3 SCREW(3X6) M3X6 4
S4 SCREW(3X8) M3X8 2
S5 SCREW(3.5X8) M3.5X8 2
S6 SCREW(3X5) M3X5 8
N1 NUT(4X0.7) M4XP0.7 2
RN Item Code No. Parts Name Specification
