Casio ZD-1

3-A
A
Note: Open the CD door and check the radiation
power with an optical power meter or by watching
the radiaation through the lens of the pickup unit at
a minimum distance of 30cm from the pickup.
Does the LASER emit ?
A1
Dose the lens move
up and down ?
A2
Load a disc and close CD door.
Then check the following.
Is the waveform
at pin 25 (FOK) of IC701 like
that shown in Fig. 16 ?
* Check IC701.
Is the waveform
at pin 31 (RFO) of IC701 like
that shown in Fig. 15 ?
* Check CN701.
* Check soldering IC701.
* Check IC701.
* Check pickup.
Is the waveform
at pin 1 (FE) of IC701 like
that shown in Fig. 17 ?
* Check pins 25, 26 and 27 of IC701.
* Check IC701.
* Check circuit around IC701.
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Figure 15
Figure 16
E
5V
!
!
!
19
E=more than 1V
Is the waveform
at pin 2 (FEI) of IC701 like
that shown in Fig. 18 ?
No
Yes
Figure 17
>2V
Figure 18
>0.3V
* Check pins 1 and 2 of IC701.
* VR704 adjustment is no good.
Readjust VR704.
(Refer to CD Adjustments)
