5. Selected track number cannot be searched.
5
Is waveform at
pin 42 (TEO) of IC701 like that
shown in Fig. 27 ?
* VR702 adjustment is no good.
Readjust VR702.
(Refer to CD Adjustments)
Is waveform at
pin 42 (TEO) of IC701 like that
shown in Fig. 28 ?
* Check CD mechanism and disc
motor.
* Check pickup.
* Check IC701.
Yes
Yes
No
No
24
Press the” “ or “ “ key.
Figure 28
Figure 27
0
0
To Next Page
