-7-
SERVICING
Adjustment of the starting microswitch for the vertical cylinder (see Fig. 9)
If despite pressing t he button S t he descent of the bu ng is very harsh, bring
the starter microswitch nearer to the limit s top by adjusting the blocking nuts.
Adjustment of the limit stop on the vertical cylinder (Se e Fig. 9)
At the en d of the wedge insertion t he limit stop activates t he microswitch which
controls the return of th e cylinder. If the wedge has not been inserted ful ly
in to the moulding screw the limit stop so as to increase th e travel.
Removing the sliding table
Unscrew the locking handle an d release th e tab l e by lifting it with the t w o fence
ti lt adjustment buttons.
Servicing t he wedge distribution are a
From time to time rem o v e th e distributor he ad (H) and cl ea n all the area in
contact with the fr o n t of the wedge cartridge with a stiff brush used dry.
Service and greasi ng
If movement becomes stick y oil the horizontal bar s (u s e 20/20 SAE oil).
Cleaning: Do not use any wet materials to rem o ve excess glue tha t has collected
o n t he machine. It helps to remove the glues if the area i s spr aye d
with a silicone grease prior to t he machine bei n g used.
To remove th e distributor head (H) undo the locki ng screw and remove
it by pulling it upwards. Remove the head, clean the ar ea underne ath
it with the aid of a small, stiff brush. Do not use d ry cleaning flu i d
IMPORTANT:
When replacing t he distributor head only tighten th e locking screw gently. Do not
overtighten.
When t he "maintenance" indicator illuminates apply grease to the hammer area.
After greasing press t he arrow an d RAZ keys simultaneously in order to
extinguish the "maintenance" indicator.
